The class to handle eoEEP_D21430. More...
#include <eoEEP_D21430.h>
Public Member Functions | |
| eoReturn | SetType (uint8_t type) |
| eoEEP_D21430 (uint16_t size=14) | |
 Public Member Functions inherited from eoD2EEProfile | |
| eoD2EEProfile (uint16_t size=14) | |
| virtual eoReturn | CreateTeachIN (eoMessage &m) |
| Generates an EEP Telegram(only not chained supported!!1) More... | |
| virtual eoReturn | SetCommand (uint8_t cmd) |
| Public Member Functions inherited from eoEEProfile | |
| eoEEProfile (uint16_t size=4) | |
| virtual eoReturn | GetValue (CHANNEL_TYPE type, float &value) |
| Gets the Value as Floating Point. More... | |
| virtual eoReturn | GetValue (CHANNEL_TYPE type, uint8_t &value) |
| Sets the Value using a unsigned integer. More... | |
| virtual eoReturn | GetValue (CHANNEL_TYPE type, uint32_t &value) |
| virtual eoReturn | GetValue (CHANNEL_TYPE type, uint8_t &value, uint8_t subFlag) |
| Gets the Value as unsigned integer. More... | |
| virtual eoReturn | GetValue (CHANNEL_TYPE type, uint32_t &value, uint8_t subFlag) |
| virtual eoReturn | GetValue (CHANNEL_TYPE type, uint64_t &value, uint8_t subFlag) |
| virtual eoReturn | GetValue (CHANNEL_TYPE type, float &value, uint8_t subFlag) |
| Gets the Value as Floating point. More... | |
| virtual eoReturn | SetValue (CHANNEL_TYPE type, float value) |
| Sets the Value using a Floating Point. More... | |
| virtual eoReturn | SetValue (CHANNEL_TYPE type, uint8_t value) |
| Sets the Value using a uint8_t. More... | |
| virtual eoReturn | SetValue (CHANNEL_TYPE type, uint32_t value) |
| virtual eoReturn | SetValue (CHANNEL_TYPE type, float value, uint8_t subFlag) |
| Gets the Value as a float. More... | |
| virtual eoReturn | SetValue (CHANNEL_TYPE type, uint8_t value, uint8_t subFlag) |
| Gets the Value as unsigned integer. More... | |
| virtual eoReturn | SetValue (CHANNEL_TYPE type, uint32_t value, uint8_t subFlag) |
| virtual eoReturn | SetValue (CHANNEL_TYPE type, uint64_t value, uint8_t subFlag) |
| Sets the Value as a 64-bit. More... | |
| virtual eoChannelInfo * | GetChannel (CHANNEL_TYPE type, uint8_t subType) |
| virtual eoChannelInfo * | GetChannel (CHANNEL_TYPE type) |
| virtual eoChannelInfo * | GetChannel (uint8_t channelNumber) |
| virtual eoReturn | GetSubTypeChannel (CHANNEL_TYPE type, std::vector< eoEEPChannelInfo *> &vector) |
| virtual uint8_t | GetChannelCount () const |
| Public Member Functions inherited from eoProfile | |
| eoProfile (uint16_t size=0) | |
| virtual bool | operator== (const eoProfile &othProfile) const |
| virtual bool | operator!= (const eoProfile &othProfile) const |
| virtual bool | IsSecDData (const eoMessage &message) |
| virtual void | ClearValues () |
| virtual eoReturn | Create (eoMessage &m) |
| Generates an EEP Message. More... | |
| virtual eoReturn | Parse (const eoMessage &msg) |
| Parses a msg using learned in Profile from Device. More... | |
| virtual uint8_t | Serialize (eoArchive &a) |
| Serialization Function which will be called by the eoStorageManager. More... | |
| eoReturn | SetManufacturer (uint16_t manufacturerID) |
Additional Inherited Members | |
| Public Attributes inherited from eoProfile | |
| uint8_t | rorg |
| R-ORG. | |
| uint8_t | func |
| Func. | |
| uint8_t | type |
| Type. | |
| uint16_t | manufacturer |
| Manufacturer. | |
| Static Protected Member Functions inherited from eoEEProfile | |
| static void | CopyItemToChannel (eoEEPChannelInfo &channel, EEP_ITEM const *item) |
| Static Protected Member Functions inherited from eoProfile | |
| static float | ScaleFromRAW (uint32_t rawValue, uint32_t rangeMin, uint32_t rangeMax, double scaleMin, double scaleMax) |
| Creates floating Point from Raw Value. More... | |
| static uint32_t | ScaleToRAW (float value, uint32_t rangeMin, uint32_t rangeMax, double scaleMin, double scaleMax) |
| Creates Raw Value from a floating Point. More... | |
| static eoReturn | GetRawValue (const eoMessage &msg, uint32_t &value, uint16_t offset, uint8_t size) |
| Gives raw data Value from a Message. More... | |
| static eoReturn | SetRawValue (eoMessage &msg, uint32_t value, uint16_t offset, uint8_t size) |
| Inserts raw data Value in a message. More... | |
| Protected Attributes inherited from eoEEProfile | |
| eoEEPChannelInfo * | channel |
| ChannelInfo list for direct Access to channels. | |
| uint8_t | channelCount |
| Number of channels. | |
| Protected Attributes inherited from eoProfile | |
| eoMessage | msg |
| helper function to convert bits | |
| Static Protected Attributes inherited from eoProfile | |
| static const uint8_t | maskArray [8] |
| Mask array. | |
The class to handle eoEEP_D21430.
Allows the user to handle eoEEP_D21430 profile.
| Channel Index | Channel Type | Type | Comment |
|---|---|---|---|
| 0 | F_ON_OFF | uint | ::SMA - Smoke Alarm status |
| 1 | F_ON_OFF | uint | ::SMA - Sensor fault mode status |
| 2 | F_ON_OFF | uint | ::SMA - Smoke Alarm Condition analysis: Maintenance |
| 3 | F_ON_OFF | uint | ::SMA - Smoke Alarm Condition analysis: Humidity |
| 4 | F_ON_OFF | uint | ::SMA - Smoke Alarm Condition analysis: Temperature |
| 5 | E_STATE | uint | ::SMA - Time since last maintenance |
| 6 | E_STATE | uint | ::SMACH0 - Time since last maintenance |
| 7 | E_STATE | uint | ::ES - Energy Storage |
| 8 | E_STATE | uint | ::RPLT - Remaining Product Life Time |
| 9 | E_STATE | uint | ::RPLTCH0 - Remaining Product Life Time |
| 10 | E_STATE | uint | ::TMP8 - Temperature |
| 11 | S_TEMP | float | ::TMP8CH0 - Temperature |
| 12 | E_STATE | uint | ::HUM - Humidity |
| 13 | S_RELHUM | float | ::HUMCH0 - Humidity |
| 14 | E_STATE | uint | ::HCI - Hygrothermal Comfort Index |
| 15 | E_STATE | uint | ::IAQTH - T/Hum. Indoor Air Analysis |
